Case Erector

Back
Case Erector
Case Erector

Machine is designed to make corrugated cardboard boxes from ready blanks by bottom forming and its sealing with adhesive tape such as scotch-tape.  It could be equipped with gluin...

Details
Video
Youtube
Type of packaging
Type of product
Show more
Get a consultation
DESCRIPTION Technical data
Machine is designed to make corrugated cardboard boxes from ready blanks by bottom forming and its sealing with adhesive tape such as scotch-tape.  It could be equipped with gluing station with gluing head for thermal glue.

Advantages

  • Wide range of corrugated boxes format
  • Possibility to use blanks  that do not meet strict requirements to the quality of cardboard and scotch tape
Name Value
Box type american case
Box length, mm 250-560
Box width, mm 200-420
Высота короба, мм 120-380
Cartboard blanks storage, pcs 150-230
Product loading height, max, mm 600
Power supply 380 V, 3ph, 50 Hz
Power consumption, kW 0,6
Air pressure, MPa 0,6
Air consumption, l/min 40
Machine length, mm 2300
Machine width, mm 2150
Machine height, mm 1400
Machine weight, kg 370
